• Net Agent II – 3Ports: Environment Measurement (Optional Kits), External modem dial in/out via PPP protocol or GSM/GPRS Modem
• Matches with shutdown software to protect computer’s file saving and shut down safely
• Auto email daily UPS history report
• Send SNMP TRAP; E-mail and SMS for events notification.
• Providing easy setup and upgrade tools via MS-Windows, just a few seconds to finish IP setting, about 1.5 minutes to upgrade firmware.
• Support TCP/IP, UDP, SNMP, Telnet, SNTP, PPP, HTTP, SMTP Protocol
• Manage and configure via Telnet, Web Browser or NMS
• Auto-sense 10M/100M Fast Ethernet
• Provide SNMP MIB to monitor & control UPS

Net Agent is a new generation SNMP (Simple Network Management Protocol) monitoring product. Not only could remote control the UPS and get the current status of it, the NetAgent II –3Ports also could provide other functions, ex. connect to Modem or GSM Modem to make the monitoring possible when there is no permanent connection to Internet and sens SMS notification . The NetAgent II – 3Ports could also been used to connect to ‘NetFeeler II’, to get the temperature, humidity and water conditions. To get the condition of Smoke detector, Gas detector, door and window detector are also possible. This product is for “Contact Closure” and “RS232” interface UPS.

The communication protocol includes the Contact Closure, RS232[MegaTec], RS232[Phoenixtec], SEC 2400, SEC 9600, Three Phase, Powerware, Smart APC, EMERSON. User could also provide their own protocol to build in. NetAgent provides a simple and easy installation procedure. CD provides along with NetAgent offers several softwares to allow the user to configure IP address; central monitoring and multi shutdown on different operating systems. Other advance configurations could be accomplished in the Web browser
